Oceanus 14
PTA dilatation balloon catheter

The dilatation balloon catheter “Oceanus 14” is a coaxial catheter (OTW, over-the-wire) designed for percutaneous transluminal angioplasty of peripheral arteries. The catheter has a coaxial double-lumen body from the proximal connector to the balloon. The guidewire runs into the inner lumen while the outer lumen allows contrast liquid passage to inflate the balloon. The maximum diameter of the guidewire must not exceed 0.36mm = 0.014”. On the distal part of the catheter, just before the tip, the balloon (inflatable segment) will dilate the artery upon inflating using infusion of contrast fluid inside it. The connector is Y-shaped, and it has two entry ports: The side port allows contrast medium passage to dilate the balloon, The straight port allows the guidewire insertion. To inflate the balloon, the connector inflation port must be connected to an inflation device. The balloon is inflated to predictable diameters with the pressure shown by the manometer. Two flexible radiopaque markers are located at each end of the balloon to mark its length and help the user see the catheter while inside the patient. At the distal end is the tip, rounded for atraumatic behavior to avoid damaging the arteries while the catheter is being advanced. The distal part, including the balloon, is coated with a durable and slippery hydrophilic coating (HYDRAX) that minimizes friction and improves catheter trackability. See IFU for further information. Available to download.

Main features:

  • Over the wire catheter (OTW)
  • Usable Catheter length: 100 cm & 150 cm
  • Guidewire compatibility: 0,014”
  • Tip profile: 0.017.”
  • Crossing profile: 0.023” to 0.033.”
  • Nominal pressure: 7 atm
  • Rated Burst Pressure (RBP): 16 atm
  • Average Burst Pressure (ABP): 22 atm
